Flat-roof PV · Kosovo

49.2 kWp Flat-Roof PV Plant in Suhareke on ISOFLAT S13 Mounts

Rows side by side on the flat roof, bird's-eye view
In brief

The 49.2 kWp flat-roof solar plant in Suhareke, Kosovo, is mounted on ISOTEC's ISOFLAT S13 system. It is fixed with ballast and the roof covering is not penetrated; the modules face south in a single row.

The project

South-facing rows on a flat roof with a parapet

The plant was built in Suhareke, Kosovo, on a flat roof surrounded by a parapet. Part of the roof is a raised separate block, and module rows were placed on both the main roof and this block.

The roof uses the ISOFLAT S13 flat-roof system. On S13 the main rail is the TFX-1400, and the modules sit in a single south-facing row on rear feet. Ballast holds the system in place and a rubber pad rests on the roof covering, so the covering is not penetrated.

Section · schematic
13°Module, facing southRUA.3 deflectorBS3 rear legballastTFX-1400 rail + SBR pad · no drilling
Schematic drawing of the general ISOFLAT S13 structure. No dimensions are given for this project.
Technical details
Capacity
49.2 kWp
Main rail
TFX-1400
System tilt
13° south
Fixing
Ballast · no drilling
Roof type
Flat roof with parapet
Scope
System supply
FAQ

Which mounting system was used on this roof in Suhareke?

ISOTEC's south-facing single-row flat-roof system ISOFLAT S13.

Was the roof covering drilled?

No. ISOFLAT S13 is fixed with ballast and the roof covering is not penetrated.

Where on the roof are the modules installed?

Module rows are placed both on the main roof surface and on the raised separate block of the roof.
