22.41 kWp Flat-Roof PV Plant in Batumi on ISOFLAT D13 Mounts

East and west rows meeting at the roof centre
In brief

The 22.41 kWp flat-roof solar plant in Batumi, Georgia, is mounted on ISOTEC's ISOFLAT D13 system. It is fixed with ballast and the roof covering is not penetrated; two module rows sit back to back facing east and west.

The project

East-west rows on a balustraded terrace roof

The plant was built in Batumi, on Georgia's Black Sea coast, on the flat roof of a classical building with a white balustrade. On the tree-lined roof the module rows form two sloping surfaces that meet along the centre line.

The roof uses the ISOFLAT D13 flat-roof system. On D13 the main rail is the TFX-2400; east- and west-facing module rows stand back to back on double rear feet in one symmetrical structure. Ballast holds the system in place and a rubber pad rests on the roof covering, so the covering is not penetrated.

Section · schematic
13°13°EASTWESTBS3 double rear legballastTFX-2400 rail · no drilling
Schematic drawing of the general ISOFLAT D13 structure. No dimensions are given for this project.
Technical details
Capacity
22.41 kWp
Main rail
TFX-2400
System tilt
13° E–W
Fixing
Ballast · no drilling
Roof type
Flat roof, balustrade
Scope
System supply
FAQ

Which mounting system was used on this roof in Batumi?

ISOTEC's east-west flat-roof system ISOFLAT D13.

Was the roof covering drilled?

No. ISOFLAT D13 is fixed with ballast and the roof covering is not penetrated.

How are the modules arranged on the roof?

The module rows form two sloping surfaces that meet along the centre line of the roof, facing east and west.
